• Product model:

  Pre-painted Galvanized Coils

  Pre-painted galvanized coils are produced by coating a layer of paint on the surface of cold rolled,galvanized or galvalume coils. Aesthetic appeal and durability are the key features of color coated steel coils. A wide selection of colors is available to the customer and paints designed to meet specific end use could be specified.Our PPGI coils are suitable for direct interior as well as exterior application, sandwich panels and so on.



  Material	DX51D,CGCC,CGCH CGLCC CGLCH
  Size Range	Thickness0.16-0.8mm,width 750-1250mm
  Temper	Full hard,half hard,soft
  Coating	AZ30--AZ160,Z50--Z140kg/m2
  Coil Weight	2--10mt
  Paint	Top side:17-25 micron,back side 5-10micron
  Color	Ral Chart,as per customer’s color swatch
  Paints	Standard Polyester(PE)



  Technical Specifications



  Test Item	Standard	Result
  T Bend	NCCA11-19	<3T
  Cupule Test	GB/T9753	>8mm
  Impact(Shock Force J)	GB/T1732	>9J
  Adhension(MEK)	GB/T9286	≥0
  Pencil Hardness	GB/T6739	>2H
  Gloss	GB/T1743	<5%
  Chromatism(E)	ECCA T3	E<5
  MEK Scrub Resistance	MCCA11-18	>100
  Salt Spray Resistance	GB/T10125	500 hr
